EA888 conical valve springs + retainers 1.8 / 2.0 TSI / TFSI NJ performance

Description

EA888 Conical Valve Springs & Steel Retainers Kit – High RPM TSI/TFSI Performance Upgrade

High-performance conical valve spring kit for Volkswagen, Audi, SEAT, and Škoda EA888 TSI and TFSI engines. Designed for high-boost and high-RPM applications, this package provides exceptional valve control, improved reliability, and increased protection against valve float.

The kit combines premium conical valve springs with lightweight hardened steel retainers and dedicated spring locators. This setup reduces valvetrain mass while maintaining excellent durability, making it suitable for both street and motorsport applications.

With the correct supporting modifications, engine speed can be safely increased to 8,000 RPM. The upgraded springs also provide an additional safety margin against accidental over-revving caused by missed shifts during aggressive driving or racing.

Unlike titanium retainers, our retainers are manufactured from a hardened tool steel alloy. They offer superior durability and wear resistance while remaining significantly lighter than many OEM retainers.

Benefits

• Prevents valve float at high RPM and high boost
• Suitable for turbocharged TSI and TFSI engine builds
• Supports engine speeds up to 8,000 RPM*
• Compatible with mild and aggressive camshaft profiles
• Increased protection against over-revving
• Lightweight hardened steel retainers
• Excellent reliability for street and motorsport use

Kit Contents

• 16 conical valve springs
• 16 lightweight hardened steel retainers
• 16 spring locators

Technical Specifications

Exhaust Springs

• Installed height pressure: 40 kg
• Pressure at 10 mm valve lift: 80 kg
• Maximum valve lift: 13.8 mm

Intake Springs

• Installed height pressure: 35 kg
• Pressure at 10 mm valve lift: 76 kg
• Maximum valve lift: 15 mm

Compatibility

Fits a wide range of EA888 TSI and TFSI engines, including:

CAWA, CCZC, CCZD, CCTA, CBFA, CAWB, CCZA, CPSA, CCZB, CAEA, CDNB, CAEB, CDNC, CHHB, CNCD, CHHA, CJXE, CJXA, CJXB, CJXD, CYFB, CJXG, CJXC, CABA, CDAA, CDAB, CDHB, and CJEB.

Applications

Ideal for high-performance street cars, track cars, drag racing applications, hybrid turbo setups, and engines equipped with upgraded camshafts.

Shipping

Price includes DHL Express delivery (1–3 working days).

For additional EA888 performance parts and engine upgrades, please visit our EA888 engine section.
